Positive PS Plate
- Printopia brand MICRO Positive PS Plate is a general purpose positive-working conventional plate
- Quick and excellent ink-water balance
- Excellent dot reproduction
- Convenient daylight handling
| Offset printing l Offset lithography l Litho-offset |
Harmonizing the very basic nature, importance and skills of plate-making – Printopia MICRO Positive PS Plate. It has been an essential material for printers.
| Features l Printopia MICRO Positive PS Plate |
- Good quality of aluminum substrate
Even electrochemical-grained substrate, dense oxidized layer, good hydrophilic with first-class aluminum material. - Less required energy
Our PS plate has the quality of high speed exposure rate and easy for processing which is a vital advantage for faster and easier imaging. - Wide latitude of development
It can be use in a diverse range of printing environments, including sheet-fed and web-fed offset presses. - Long run length
It could sustain the corrosive chemicals and deliver high impression up to 200,000 runs with unbaked and above 1,000,000 runs with baked.
| Specifications l Size |
Please directly contact us for detailed catalog.
| Offset Printing Plate ∣ Common size (mm) |
||
| 1030 X 770 |
1030 X 785 |
1030 X 790 |
| 1030 X 795 |
1030 X 800 |
915 X 715 |
| 925 X 740 |
745 X 605 |
670 X 560 |
| 650 X 550 |
510 X 400 |
450 X 370 |
| Offset Printing l Articles and Video |
- Youtube Video -
| Printopia MICRO Offset PS Printing Plate |
Please directly contact us for detailed technical date sheet for processing with our plates.
| Plate Type | Positive-working conventional plate with optional post-bake for longer runs |
| Thickness / Gauge | 0.15 / 0.20 / 0.25 / 0.30 / 0.40 mm |
| Colour |
|
| Shelf Life | 24 months under standard storage conditions |
| Substrate | Electro-chemically grained and anodized lithographic aluminum |
| Compatible Platesetter | All the common platesetter brands in the market |
| Operation Term | |
| Imaging |
|
| Safelight | Handling under UV-free yellow safelight |
| Spectral Sensitivity | 360-420nm |
| Required Imaging Energy | 80 mJ/ cm² |
| Resolution | 1-99%@200lpi |
| Processing |
|
| Developer | Printopia Developer or other common brands in market |
| Developer dilution | 1:5 recommended |
| Replenishing Rate | 60ml/ m² |
| Processing Temperature | 23-27 ℃ |
| Processing Dwell Time | 20-40 seconds |
| On-press |
|
| Run Length |
|
| Plate Baking | 220 degrees Celsius for 5 minutes |
| Storage Conditions |
|
